Customized Heat Resistant Fire Resistant Screw Conveyor Spiral Conveyor for Cement and Construction

Customized Heat Resistant Fire Resistant Screw Conveyor Spiral Conveyor for Cement and Construction

Brand Name:	WeSeW
MOQ:	1 pc
Price:	US$8,000~US$30,000 per pc
Payment Terms:	T/T,Western Union
Supply Ability:	10,000 pieces per month

Detail Information

Product Description

Detail Information

Place of Origin:

china

Certification:

CE/UL

Model NO.:

KX0014-1

Material:

Stainless Steel

Material Feature:

Heat Resistant, Fire Resistant

Application:

Chemical Industry, Grain Transport, Mining Transport, Power Plant

Condition:

New

Product Name:

Spiral Machine Screw Conveyor

Applicable Industries:

Manufacturing Plant, Food & Beverage Factory...

Machinery Test Report:

Provided

Core Components:

Motor, Gearbox, Casing, Circle Blade

Dimension(L*W*H):

Customized

Transport Package:

Wooden Box

Specification:

Customized

Trademark:

WESEW

Origin:

China

Supply Ability:

500000/Year

Package Size:

500.00cm * 60.00cm * 50.00cm

Package Gross Weight:

100.000kg

After-sales Service:

Provided

Warranty:

1 Year

Structure:

Conveyor System

Customization:

Available Customized Request

Shipping Cost:

About Shipping Cost And Estimated Delivery Time.

Currency:

US$

Return&refunds:

You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Packaging Details:

Wooden Case

Supply Ability:

10,000 pieces per month

Highlight:

Carbon steel Continuous Screw Conveyor Cement

Construction Screw Conveyor Cement

Spiral Cement Silo Screw Conveyor

Product Description

Spiral Carbon Steel Screw Conveyor for Cement Construction

OEM custom continuous screw conveyor spiral machine designed specifically for cement applications in construction and manufacturing environments.

Technical Specifications

Applicable Industries	Building Material Shops, Manufacturing Plant, Construction
Material	Carbon Steel
Structure	Conveyor System
Power Options	3W, 4W, 5.5W, 7.5W, 11W, 15W, 18.5W, 22W, 30W
Warranty	1 Year
Core Components	Motor, Other
Use	Screw conveyor for concrete batching plant
Control System	Automatic Control System
Condition	New
Material Feature	Fire Resistant
Voltage	380V/50Hz
Regular Diameter	165mm, 219mm, 273mm, 323mm, 407mm

Product Introduction

Screw conveyors transport materials using rotating spiral blades or by rotating the spiral side and tank together. In dry mortar production lines, powder materials are transmitted via screw conveyor, with feeding controlled by starting and stopping the spiral blade rotation.

The conveyor operates within a completely sealed cavity body to prevent environmental contamination and protect materials from moisture-induced agglomeration. Tubular screw conveyors are typically used for transporting cement and compound materials.

Screw conveyors typically operate at angles up to 45°, with maximum angles reaching 60°. Different lengths can be achieved by adding or reducing standard sections, with each screw not exceeding 14 meters in length. Spiral relay systems can be implemented for longer transport distances.

Key Features

Constructed from high-quality steel with excellent overall structural integrity
Double pitch blades reduce material compression during transport
High-quality reducer provides high torque with low noise operation
Universal joint connection for convenient installation
One-piece blade formation prevents material blockage
