Electric Mortar Sprayer Machine with Adjustable Feeding Angle Low Noise and High Feeding Accuracy

Electric Mortar Sprayer Machine with Adjustable Feeding Angle Low Noise and High Feeding Accuracy

Brand Name:	WeSeW
Model Number:	KP001-1
MOQ:	1 pc
Price:	US$420~US$950 per pc
Payment Terms:	T/T,Western Union
Supply Ability:	10,000 pieces per month

Detail Information

Product Description

Detail Information

Place of Origin:

china

Certification:

CE/UL

Features:

Durable, Easy To Clean, Low Noise

Capacity:

1000kg/h

Feeding Angle:

Adjustable

Voltage:

Customize

Material:

Stainless Steel

Application:

Walls，Bridges，Dam，Tunnel

Power Source:

Electric

Product Type:

Industrial Equipment

Feeding Accuracy:

High

Packaging Details:

Wooden Case

Supply Ability:

10,000 pieces per month

Highlight:

Electric Mortar Sprayer Machine

Low Noise Mortar Sprayer Machine

Electric Spray Plaster Machine

Product Description

Electric Mortar Sprayer Machine - Low Noise & Adjustable Feeding Angle

OEM Electric Concrete Mortar Spraying Pumping Machine

Professional plaster rendering machine designed for efficient mortar application with adjustable feeding angles and low noise operation.

Technical Specifications

Model 511 Mortar Spraying Machine

Parameter	Specification
Dimensions	1600×450×950mm
Total Weight	150kg
Transport Flow	220 m²/hour
Motor Power	4.0kW
Air Compressor Power	2.2kW
Voltage	380V/220V
Through Particles	≤4mm
Conveying Pipe Diameter	32#
Vertical Conveying Distance	10 meters (material dependent)
Horizontal Conveying Distance	15 meters (material dependent)
Spray Materials	Mortar, putty, plaster, paint, etc.

Model 711 Mortar Spraying Machine

Parameter	Specification
Dimensions	1700×600×1100mm
Total Weight	250kg
Transport Flow	300 m²/hour
Motor Power	7.5kW
Air Compressor Power	3.0kW
Voltage	380V
Through Particles	≤5mm
Conveying Pipe Diameter	32#
Vertical Conveying Distance	20 meters (material dependent)
Horizontal Conveying Distance	30 meters (material dependent)
Spray Materials	Mortar, putty, plaster, paint, etc.

Model 311 Mortar Spraying Machine

Parameter	Specification
Vertical Conveying Distance	10m
Horizontal Conveying Distance	20m
Weight (Bare Metal/Packaged)	180kg / 200kg
Motor Power	Main Motor 4kW / Air Pump Motor 2.2kW
Maximum Mortar Ratio	1:3
Mortar Delivery Volume	1.5m³
Work Efficiency	100 m²/h
Hopper Volume	60L
Dimensions (L×W×H)	1300×450×750mm
Packaging Size	1530×530×1100mm
Material Tube Inner Diameter	32mm
Work Pressure	3-6 MPa
Voltage	380V/220V
Maximum Passing Particles	5mm
Application Scope	Mortar putty coating, etc.

Please specify your preferred model when ordering

Company Capabilities

Our Strengths

Efficient team with many years of experience
High quality products at competitive prices
Excellent manufacturing equipment
Timely delivery guaranteed

Manufacturing Services

CNC Turning & Milling

Laser Cutting & Wire Cutting

Stamping, Bending & Painting

Injection Molding

Casting, Punching & Welding

Tapping, Riveting & Threading

Available Materials

Aluminum Alloys: 5052, 6061, 6063, 6082, 2017, 7075, etc.

Stainless Steel: 303, 304, 316, 412, etc.

Steel Alloys: Steel, Die Steel, Spring Steel, etc.

Brass Alloys: 260, C360, H59-H70, Bronze, Copper

Titanium Alloys: Grade F1-F5

Plastic Alloys: POM, PA, Nylon, PC, PMMA, PVC, PU, Acrylic, ABS, PTFE, PEEK

Special Materials: Cr12, Carbon Fiber

Surface Treatments

Anodizing, Bead blasting, Silk screening, PVD Plating, Zinc/Nickel/Chrome/Titanium Plating, Brushing, Painting, Powder coating, Passivation, Electrophoresis, Electro polishing, Knurling, Laser/Etch/Engraving

Industry Applications

Medical equipment, electronic equipment, communication equipment, semiconductor equipment, mechanical equipment, automation equipment, new energy, petroleum, automotive, aviation, motorcycle, bicycle, optical equipment, architecture, sports equipment, molds, etc.

Technical Details

File Formats	STP/STEP, AutoCAD (DXF, DWG), SolidWorks, Pro/Engineer, PDF, TIF
Sample Time	3-7 Working Days
Bulk Production Time	8-30 Working Days
Minimum Order Quantity	1 piece (Low MOQ to minimize waste)
Shipping Options	Sea freight: 20-60 days • Air & Land freight: 7-15 days
Payment Methods	PayPal, Mercado Pago, Western Union, Visa/MasterCard debit & credit cards

Product Overview

The concrete sprayer machine utilizes compressed air to convey mortar and concrete materials through a hose and nozzle system, providing efficient application on various surfaces with precision and consistency.

Practical Applications

Construction Sites: Protective coating and repair of building exteriors, floors, and structural components
Road Construction: Repair and reinforcement of roads, bridges, and sidewalks
Underground Projects: Structural reinforcement for tunnels, basements, and subterranean facilities
Water Conservancy: Dam, dike, and canal repair and strengthening
Mining Operations: Spray application and repair of mine shafts and mining roads

Key Advantages

High Efficiency: Rapid, uniform material application over large areas increases productivity

Eco-Friendly Operation: Precise spray volume control minimizes material waste

Versatile Compatibility: Suitable for various concrete and mortar types

User-Friendly Design: Simple operation requiring minimal technical expertise
