U-shaped Stainless Steel Shaftless Spiral Drill Blade Ash Cement Sludge Pipe Spiral Conveyor

U-shaped Stainless Steel Shaftless Spiral Drill Blade Ash Cement Sludge Pipe Spiral Conveyor

Brand Name:	WeSeW
Model Number:	SS-717
MOQ:	1 pc
Price:	Price Negotiation
Payment Terms:	T/T, Western Union
Supply Ability:	1000000pcs per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,UL

Features:

Flexible, Easy To Clean, Low Maintenance

Voltage:

220V

Control System:

Manual Or Automatic

Screw Type:

Helicoid Or Sectional

Design:

Spiral

Strength:

High Tensile Strength

Discharge Height:

Customizable

Drive Type:

Direct Drive Or Chain Drive

Packaging Details:

Wooden Case

Supply Ability:

1000000pcs per month

Highlight:

Sludge Pipe Spiral Conveyor

Ash Spiral Conveyor

Cement Spiral Conveyor

Product Description

U-shaped Stainless Steel Shaftless Spiral Drill Blade Ash, Cement, Sludge Pipe Spiral Conveyor

Spiral Conveyor Function

Efficient Conveyance: Suitable for horizontal or inclined conveyance of powdered, granular, and small lumpy materials such as grains, coal, flour, cement, etc., with high conveyance efficiency.

Versatile Applicability: Can be used in environmental temperatures ranging from -20 to 50 ℃, with conveyed material temperatures not exceeding 200 ℃, adapting to various working environments.

Fully Enclosed Design: The fully enclosed structure effectively prevents the leakage of dust, corrosive, or hazardous substances, ensuring the safety and hygiene of the working environment.

Spiral Conveyor Application

1.Food Processing: Used for conveying food raw materials such as grains and flour.

2.Pharmaceuticals: Suitable for conveying pharmaceutical raw materials such as powdered medicine and granules.

3.Powder and Energy: Used for conveying energy materials such as coal and fly ash.

4.Petrochemicals: Suitable for conveying petrochemical raw materials and fertilizers.

5.Mining and Minerals: Used for conveying mineral materials such as ore and ore powder.

Spiral Conveyor Technical Parameters

Attribute	Description
Material	U-shaped Stainless Steel
Structure Type	Shaftless Spiral Drill Blade
Conveyed Materials	Powdered, Granular, and Small Lumpy Materials
Applicable Industries	Building Materials, Chemical, Coal, Grain & Oil, Feed, etc.
Conveyance Mode	Horizontal or Inclined
Ambient Temperature	-20 ~ 50 ℃
Material Temperature	≤ 200 ℃
Characteristics	Not Suitable for Perishable, Sticky, or Agglomerated Materials
Driving Devices	Motor, Reducer, Coupling, or Drive Chain
Main Components	Screw Shaft (Main Shaft and Blade), Enclosed Housing, Cover Plate, Feed Inlet, Sealing Plates at Both Ends, and Bearings
Advantages	Cost-effective, Efficient Material Distribution, Fully Enclosed Dust-proof
Application Scenarios	Food Processing, Pharmaceuticals, Powder & Energy, Petrochemicals, Chemicals, Mining & Minerals, Feed Processing, Plastics, etc.
