Fire Resistant Stainless Steel Customized Screw Auger Feeder with Hopper for Grain Transport

Fire Resistant Stainless Steel Customized Screw Auger Feeder with Hopper for Grain Transport

Brand Name:	WeSeW
MOQ:	1 pc
Price:	US$800~US$8,000 per pc
Payment Terms:	T/T,Western Union
Supply Ability:	10,000 pieces per month

Detail Information

Product Description

Detail Information

Place of Origin:

china

Certification:

CE/UL

Model NO.:

KX0021-1

Material:

Stainless Steel

Material Feature:

Heat Resistant, Fire Resistant

Application:

Chemical Industry, Grain Transport, Mining Transport, Power Plant

Condition:

New

Product Name:

Auger Feeder Screw Augers Conveyor

Dimension(L*W*H):

Customized

Applicable Industries:

Manufacturing Plant, Food & Beverage Factory...

Machinery Test Report:

Provided

Core Components:

Motor, Gearbox, Casing, Circle Blade

Transport Package:

Wooden Box

Specification:

Customized

Trademark:

WESEW

Origin:

China

Supply Ability:

500000/Year

Package Size:

500.00cm * 60.00cm * 80.00cm

Package Gross Weight:

100.000kg

After-sales Service:

Provided

Warranty:

1 Year

Structure:

Roller Conveyor

Customization:

Available Customized Request

Shipping Cost:

About Shipping Cost And Estimated Delivery Time.

Currency:

US$

Return&refunds:

You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Packaging Details:

Wooden Case

Supply Ability:

10,000 pieces per month

Highlight:

Fire Resistant Screw Auger Feeder

Inclined Screw Auger Feeder

Product Description

Fire Resistant Inclined Semolina Auger Feeder Screw Augers Conveyor with Hopper

Product Specifications

Applicable Industries	Energy & Mining, Chemical, Metallurgy, Building Material
Material	Carbon steel
Structure	U-shape screw conveying
Power	1.5-18.5kW
Warranty	1 Year
Core Components	Spiral wind turbines, Vortex air pump
Condition	New
Material Feature	Abrasion resistant
Voltage	110V / 220V / 380V / As client's demand
Dimensions	Size customized
Quality Assurance	Machinery Test Report Provided, Video outgoing-inspection Provided

Product Overview

This U-shape screw conveyor is designed for efficient material handling of powder, granular, and small lump materials including cement, coal powder, grain, fertilizer, ash, slag, and sand. The fire-resistant inclined semolina auger feeder features a hopper and is unsuitable for materials that are prone to deterioration, sticky, or excessively lumpy.

Applications & Operating Parameters

Widely utilized across building materials, chemical, electric power, coal, metallurgy, and grain industries. Suitable for horizontal and inclined arrangements with maximum inclination of 20°. Operating environment temperature ranges from -20°C to 50°C, with material temperature capacity up to 200°C. Maximum vertical lifting height is 8 meters.

Key Advantages

Simple structure with compact cross-sectional design
Excellent sealing performance for dust-free operation
Multiple loading and discharge points capability
Safe, convenient operation with low maintenance requirements
Cost-effective manufacturing and operation
High reliability and extended service life
Strong adaptability to various industrial applications
Easy installation and maintenance procedures

Structural Design

The screw conveyor comprises three main components: conveyor body, discharge outlet, and driving mechanism. The body structure includes first, middle, and tail sections with specialized bearing arrangements. The first section incorporates thrust bearings for axial force management, while middle and tail sections feature support bearings. The tail section includes radial bearings with axial movement capability to accommodate shaft length variations and temperature changes. Available in both single shaftless and double shaftless configurations to meet diverse operational requirements.
