High Speed Heat Resistant Customized Screw Auger Conveyor for Coal Mine and Chemical Industry

Name: High Speed Heat Resistant Customized Screw Auger Conveyor for Coal Mine and Chemical Industry
Brand: Guangzhou Kaixi Wisdom Valley Technology Co.,Ltd
SKU: Kai003
Price: 15.00 USD
Availability: InStock

Brand Name:	WeSeW
Model Number:	Kai003
MOQ:	1 pc
Price:	US$10,000~US$20,000 per pc
Payment Terms:	T/T,Western Union
Supply Ability:	10,000 pieces per month

Detail Information

Product Description

Detail Information

Place of Origin:

china

Certification:

CE/UL

Model NO.:

Kai003

Material:

Stainless Steel

Material Feature:

Heat Resistant, Fire Resistant

Application:

Chemical Industry, Grain Transport, Mining Transport, Power Plant

Condition:

New

Applicable Industries:

Manufacturing Plant, Food & Beverage Factory...

Machinery Test Report:

Provided

Usage:

Conveyor

Width Or Diameter:

Customized

Dimension(L*W*H):

Customized

Function:

Transmission System

Feature:

High Efficiency

Speed:

High Speed

Transport Package:

Wooden Box

Specification:

Customized

Trademark:

WESEW

Origin:

China

Supply Ability:

500000/Year

Package Size:

800.00cm * 100.00cm * 100.00cm

Package Gross Weight:

300.000kg

After-sales Service:

Provided

Warranty:

1 Year

Structure:

Conveyor System

Customization:

Available Customized Request

Shipping Cost:

About Shipping Cost And Estimated Delivery Time.

Currency:

US$

Return&refunds:

You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Packaging Details:

Wooden Case

Supply Ability:

10,000 pieces per month

Highlight:

Heavy Screw Auger Conveyor

Carbon Steel Screw Auger Conveyor

Coal Mine Flexible Auger Conveyor

Product Description

High Speed Heavy Carbon Steel Screw Auger Conveyor Customized For Coal Mine

OEM Custom Cooling Or Heating Optional U Trough Double Auger Screw Conveyor

Configuration Options

Feature	Options
Auger types	Single/Twin/Multi screw
Instrumentation	Temperature in/out readout, Flowmeters, Variety of pressure gauges available, Customized control panels
Seal types	Rotating Mechanical, Packing Gland, Custom
Heaters/Coolers	Single, dual or triple zone configurations, -50°F to 600°F temperature control, Designed for your needs
Jacket types	Heating jackets, Cooling jackets, Integral or bolt-on, ASME "U" and "R" stamp
Customization	Inlet and outlet custom designs, Built-to-order support stands, NDE and X-ray options, Various insulation options
Sample applications	Drying, Polymerization, Heat curing, Cooling/freezing, Microbial kill, Sintering/calcining, Dewatering

Product Overview

Heat Systems screw conveyors are simple, robust and flexible, often employed to adjust the temperature of a solid material prior to storage or further processing. The unit is essentially a screw conveyor with heat transfer capability, providing both material movement and temperature adjustment in one device.

Other suppliers typically employ an external jacket to act as the sole heat transfer surface. The problem is that this surface has limited contact with the material due to voidage and movement, generally resulting in a larger unit than necessary being specified to compensate. However, the Heat Systems screw conveyors also use the screw itself to supply or withdraw heat, thereby penetrating deep into the solid which is often a poor conductor (e.g. spent carbon). This effectively results in a smaller, more compact footprint and cost.

A liquid heat transfer medium ensures stable and precise control of the final product temperature (e.g. cooling water, thermal oil, glycol etc). As always, custom screw conveyor designs are available to suit your individual need.

Key Features

Thermal treatment is accomplished while the product material is conveyed for cost savings
Control of temperature during material transfer for maximum efficiency
Accurate control of thermal treatment time ensures precise requirements are met
Greater heat transfer surface area per unit of product than batch mixer systems
Bolt-on or integral external thermal heating and cooling jacket

Technical Advantages

Efficient Heat Transfer

The thermascrew provides full heat surface utilization with both a heated vessel and rotor. The rotor's short-pitch screw design promotes gentle material tumbling, promoting more uniform and efficient heat transfer.

Residence Time Control

Near plug-flow operation means consistent time and temperature exposure for treating material and providing controlled, narrow residence time distribution.

Minimize Processing Damage

Even treatment and slow mixing action minimizes burning, sticking, abrasion, dusting, crushing, or breaking.

Thick Material Processing

Twin-rotor designs are available to process difficult, dough or paste-like materials. Intermeshing flights on the rotor helps promote more even heat-transfer while preventing sticking and promoting self-cleaning.

Steam Injection

Optional injection capabilities inject steam into the material for cooking or sterilizing applications.

Operating Cost Savings

Material is heated, cooled, mixed, or dried as it is conveyed, resulting in lower costs, increased efficiency and no product damage or spillage.

Industry Applications

Heating and cooling screw conveyors are used around the globe in industries such as biomass conversion, paper and pulp, biofuels, food and dairy, chemicals, petrochemicals, minerals processing, and many more.
