Stainless Steel Heat Resistant Customized Screw Conveyor Auger Conveyor for Powder and Grain Transport

Stainless Steel Heat Resistant Customized Screw Conveyor Auger Conveyor for Powder and Grain Transport

Brand Name:	WeSeW
MOQ:	1 pc
Price:	US$8,000~US$30,000 per pc
Payment Terms:	T/T,Western Union
Supply Ability:	10,000 pieces per month

Detail Information

Product Description

Detail Information

Place of Origin:

china

Certification:

CE/UL

Model NO.:

KX0014

Material:

Stainless Steel

Material Feature:

Heat Resistant, Fire Resistant

Application:

Chemical Industry, Grain Transport, Mining Transport, Power Plant

Condition:

New

Product Name:

Continuous Flour Feeder Conveyor System

Applicable Industries:

Manufacturing Plant, Food & Beverage Factory...

Machinery Test Report:

Provided

Core Components:

Motor, Gearbox, Casing, Circle Blade

Dimension(L*W*H):

Customized

Transport Package:

Wooden Box

Specification:

Customized

Trademark:

WESEW

Origin:

China

Supply Ability:

500000/Year

Package Size:

500.00cm * 60.00cm * 50.00cm

Package Gross Weight:

100.000kg

After-sales Service:

Provided

Warranty:

1 Year

Structure:

Conveyor System

Customization:

Available Customized Request

Shipping Cost:

About Shipping Cost And Estimated Delivery Time.

Currency:

US$

Return&refunds:

You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Packaging Details:

Wooden Case

Supply Ability:

10,000 pieces per month

Highlight:

2024 Heavy Duty Screw Auger Conveyor

Long Stainless Steel Screw Auger Conveyor

Powder Spiral Tube Screw Auger Conveyor

Product Description

Heavy Duty Stainless Steel Screw Conveyor System

Product Overview

Custom OEM cement, sand, powder, and continuous flour feeder conveyor system designed for industrial applications with automatic control and efficient material handling.

Specification	Details
Applicable Industries	Building Material Shops, Manufacturing Plant, Construction
Material	Carbon steel
Structure	Conveyor System
Power Options	3w, 4w, 5.5w, 7.5w, 11w, 15w, 18.5w, 22w, 30w
Warranty	1 Year
Core Components	Motor, Other
Primary Use	Screw conveyor for concrete batching plant
Control System	Automatic Control System
Voltage	380V/50Hz
Regular Diameter	165mm, 219mm, 273mm, 323mm, 407mm

Technical Specifications

Operating Principle

Screw conveyor transports materials using rotating spiral blades or spiral side and rotating tank mechanisms. Designed for dry mortar production lines, this system controls powder material feeding through spiral blade rotation and stop functions. The completely sealed cavity body prevents environmental contamination and protects materials from moisture-induced agglomeration.

Operating Parameters

Standard operation angles up to 45°, with maximum angles reaching 60°. Customizable lengths achieved by adding or reducing standard sections, with maximum single screw length of 14m. Spiral relay systems available for longer transport distances.

Key Features

High-quality steel construction with excellent overall integrity
Double pitch blades reduce material compression during transport
Premium reducer with high torque and low noise characteristics
Universal joint connection for convenient installation
One-piece blade forming prevents material blockage

Technical Drawing
