Heat Resistant Customized Screw Auger Feeder for Pneumatic Conveying System Rigid Impeller Star Discharger

Heat Resistant Customized Screw Auger Feeder for Pneumatic Conveying System Rigid Impeller Star Discharger

Brand Name:	WeSeW
MOQ:	1 pc
Price:	US$300~US$1,000 per pc
Payment Terms:	T/T,Western Union
Supply Ability:	10,000 pieces per month

Detail Information

Product Description

Detail Information

Place of Origin:

china

Certification:

CE/UL

Model NO.:

AC0051

Material:

Carbon Steel

Material Feature:

Heat Resistant, Fire Resistant

Application:

Chemical Industry, Grain Transport, Mining Transport, Power Plant

Condition:

New

Applicable Industries:

Industry

Machinery Test Report:

Provided

Core Components:

Motor

Dimension(L*W*H):

Customized

Transport Package:

Wooden Box

Specification:

Customized

Trademark:

WESEW

Origin:

China

Supply Ability:

500000/Year

Package Size:

80.00cm * 60.00cm * 200.00cm

Package Gross Weight:

100.000kg

After-sales Service:

Provided

Warranty:

1 Year

Structure:

Conveyor System

Customization:

Available Customized Request

Shipping Cost:

About Shipping Cost And Estimated Delivery Time.

Currency:

US$

Return&refunds:

You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Packaging Details:

Wooden Case

Supply Ability:

10,000 pieces per month

Highlight:

Rigid Impeller Feeder Auger Conveyor

Star Discharger Auger Conveyor

Pneumatic Conveying System Auger Conveyor

Product Description

Rigid Impeller Feeder Star Discharger for Pneumatic Conveying System

The Rigid Impeller Feeder Star Discharger is designed for pneumatic conveying systems and auger conveyors, providing uniform discharge and feeding of dry powders and small particles in industrial applications.

Product Specifications

Applicable Industries	Building Material Shops, Machinery Repair Shops, and related industrial sectors
Material	Carbon steel or customized according to customer requirements
Structure	Conveyor System
Warranty	1 Year
Core Components	Motor, Bearing, Gear, Gearbox
Function	Uniform discharge or feeding
Temperature of Media	Medium Temperature
Material Feature	Heat Resistant
Dimension (LWH)	Customizable
Color	According to customer requirements
Application	General use, For silo, Bulk material handling

Product Applications

GY type rotary feeder is used to feed dry powder or small particles continuously and evenly from the upper bin to the next equipment. This machine is suitable for thermal power plant dust collectors, air preheaters, economizer equipment discharging outlets, dry ash conveying pipes, air lock systems, and uniform feeding applications. It is also widely used in chemical plants, cement plants, food processing, and other industrial sectors requiring pneumatic conveying systems.

Working Principle

The GY type rotary impeller feeder operates as a quantitative feeding equipment. The machine is equipped with YTC series reduction motor or XWD system cycloidal reducer. The motor drives the shaft and impeller rotation through elastic cylindrical pin coupling or sprocket drive. Material enters from the upper housing through the inlet into the groove, where the rotating impeller carries the material to the discharge outlet, achieving uniform feeding objectives.

Key Features

Uniform and continuous material discharge
Heat-resistant construction materials
Customizable dimensions and specifications
Suitable for dry powders and small particles
Versatile applications across multiple industries
Reliable motor and gearbox components

Product Display
