Easy Installation Energy Saving Stainless Steel Screw Auger Conveyor for Material Handling

Name: Easy Installation Energy Saving Stainless Steel Screw Auger Conveyor for Material Handling
Brand: Guangzhou Kaixi Wisdom Valley Technology Co.,Ltd
SKU: Kai001
Price: 19.00 USD
Availability: InStock

Brand Name:	WeSeW
Model Number:	Kai001
MOQ:	1 pc
Price:	US$8,000~US$30,000 per pc
Payment Terms:	T/T,Western Union
Supply Ability:	10,000 pieces per month

Detail Information

Product Description

Detail Information

Place of Origin:

china

Certification:

CE/UL

Model NO.:

Kai001

Material:

Stainless Steel

Material Feature:

Heat Resistant, Fire Resistant

Application:

Chemical Industry, Grain Transport, Mining Transport, Power Plant

Condition:

New

Applicable Industries:

Industry

Machinery Test Report:

Provided

Core Components:

Motor

Dimension(L*W*H):

Customized

Transport Package:

Wooden Box

Specification:

Customized

Trademark:

WESEW

Origin:

China

Supply Ability:

500000/Year

Package Size:

900.00cm * 80.00cm * 85.00cm

Package Gross Weight:

200.000kg

After-sales Service:

Provided

Warranty:

1 Year

Structure:

Conveyor System

Customization:

Available Customized Request

Shipping Cost:

About Shipping Cost And Estimated Delivery Time.

Currency:

US$

Return&refunds:

You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Packaging Details:

Wooden Case

Supply Ability:

10,000 pieces per month

Highlight:

Easy Installation Flexible Spiral Conveyor

Energy Saving Flexible Spiral Conveyor

Material Handling Screw Feeder Conveyor

Product Description

Stainless Steel Spiral Auger Conveyor

OEM custom stainless steel spiral auger conveyor designed for efficient material handling with easy installation and energy-saving operation.

Product Specifications

Model	SLS300-3500
Applicable Industries	Food & Beverage Factory, Construction works, Cement, etc.
Material	Stainless steel, Carbon steel
Structure	Conveyor System
Warranty	1 Year
Core Components	Motor, Bearing
Feeding Material	Powder or granule
Length	Customized 1~30m
Processing	Painting, burnishing, Bead blasting
Speed	Adjustable Speed
Material Feature	Heat Resistant
Type	Tube, trough, shaftless, vertical

Product Introduction

The double-shaft screw conveyor features a solid screw in a U-shaped groove with left-handed and right-handed configurations. When operating, the two screws rotate through a gear pair at the shaft extension, enabling axial material movement for efficient conveying.

Working Principle

Material enters through the feed port. As the rotating shaft turns, the helical blades apply normal thrust to the material. While radial components and blade friction could cause rotation, material gravity and trough friction prevent this, resulting in controlled axial movement along the trough.

Key Features

Left-handed and right-handed combined conveying system
Large cross-sectional area for enhanced conveying capacity
Multi-functional capabilities including conveying, stirring, crushing, and pushing

Technical Parameters

Serial No.	Model	Conveyance Capacity (m³/h)	Power (kw)	Groove Inner Width (mm)	Material
1	SLS100	0.1-0.5	Specifically customized according to material, conveying volume and angle	198	carbon steel/stainless steel
2	SLS150	0.3-1.5	Specifically customized according to material, conveying volume and angle	294	carbon steel/stainless steel
3	SLS200	0.8-4.0	Specifically customized according to material, conveying volume and angle	388	carbon steel/stainless steel
4	SLS250	1.5-7.5	Specifically customized according to material, conveying volume and angle	486	carbon steel/stainless steel
5	SLS300	5.0-13.00	Specifically customized according to material, conveying volume and angle	576	carbon steel/stainless steel

Scope of Application

Suitable for powdery, granular and small block materials in chemical industry, environmental protection, food and other industrial applications.

Product Documentation

Machinery Test Report: Provided

Video Outgoing-inspection: Provided

After-Sales Service

After Warranty Service: Video technical support, Online support

After-sales Service Provided: Online support
