Industrial Fire Resistant 304 Stainless Steel Screw Feeder Conveyor with Customized Dimensions

Name: Industrial Fire Resistant 304 Stainless Steel Screw Feeder Conveyor with Customized Dimensions
Brand: Guangzhou Kaixi Wisdom Valley Technology Co.,Ltd
SKU: Kai001
Price: 19.00 USD
Availability: InStock

Brand Name:	WeSeW
Model Number:	Kai001
MOQ:	1 pc
Price:	US$8,000~US$30,000 per pc
Payment Terms:	T/T,Western Union
Supply Ability:	10,000 pieces per month

Detail Information

Product Description

Detail Information

Place of Origin:

china

Certification:

CE/UL

Model NO.:

Kai001

Material:

Stainless Steel

Material Feature:

Heat Resistant, Fire Resistant

Application:

Chemical Industry, Grain Transport, Mining Transport, Power Plant

Condition:

New

Applicable Industries:

Industry

Machinery Test Report:

Provided

Core Components:

Motor

Dimension(L*W*H):

Customized

Transport Package:

Wooden Box

Specification:

Customized

Trademark:

WESEW

Origin:

China

Supply Ability:

500000/Year

Package Size:

750.00cm * 100.00cm * 30.00cm

Package Gross Weight:

200.000kg

After-sales Service:

Provided

Warranty:

1 Year

Structure:

Conveyor System

Samples:

US$ 1120/Set 1 Set(Min.Order) |

Customization:

Available | Customized Request

Shipping Cost:

About Shipping Cost And Estimated Delivery Time.

Currency:

US$

Return&refunds:

You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Packaging Details:

Wooden Case

Supply Ability:

10,000 pieces per month

Highlight:

Fire Resistant Screw Feeder Conveyor

Industrial Screw Feeder Conveyor

Stainless Steel Roller Spiral Screw Conveyor

Product Description

Industrial Fire Resistant Screw Feeder Conveyor with 304 Stainless Steel Roller

OEM Custom Stainless Steel Spiral Auger Conveyor

Model	SLS300-3500
Applicable Industries	Food & Beverage Factory, Construction works, Cement
Material	Stainless steel, Carbon steel
Structure	Conveyor System
Warranty	1 Year
Core Components	Motor, Bearing
Feeding Material	Powder or granule
Length	Customized 1~30m
Processing	Painting, burnishing, Bead blasting
Speed	Adjustable Speed
Material Feature	Heat Resistant
Type	Tube, trough, shaftless, vertical

Product Introduction

The double-shaft screw conveyor is equipped with solid screws in a U-shaped groove, featuring one left-handed and one right-handed screw. When operating, the two screws rotate through a pair of gears at the shaft extension position. The rotation of the spiral body moves material axially to achieve efficient conveying.

Working Principle

Material flows in from the feed port. When the rotating shaft rotates, the material receives normal thrust from the helical blade. The radial component of this thrust and the friction force of the blade on the material may drive rotation around the axis, but due to material gravity and trough friction, the material doesn't rotate with the helical blade. Instead, it moves axially along the trough under the axial component of the blade's normal thrust.

Key Features

Left-handed and right-handed combined conveying system
Large cross-sectional area for increased conveying capacity
Multiple physical functions including conveying, stirring, crushing, and pushing

Technical Parameters

Serial No.	Model	Conveyance Capacity (m³/h)	Power (kw)	Groove Inner Width (mm)	Material
1	SLS100	0.1-0.5	Specifically customized according to material, conveying volume and angle	198	carbon steel/stainless steel
2	SLS150	0.3-1.5	Specifically customized according to material, conveying volume and angle	294	carbon steel/stainless steel
3	SLS200	0.8-4.0	Specifically customized according to material, conveying volume and angle	388	carbon steel/stainless steel
4	SLS250	1.5-7.5	Specifically customized according to material, conveying volume and angle	486	carbon steel/stainless steel
5	SLS300	5.0-13.00	Specifically customized according to material, conveying volume and angle	576	carbon steel/stainless steel

Scope of Application

Suitable for powdery, granular and small block materials in chemical industry, environmental protection, food and other industrial applications.
