Easy to Operate High Mixing Capacity Customizable Powder Mixing Machine Horizontal Ribbon Mixer

Easy to Operate High Mixing Capacity Customizable Powder Mixing Machine Horizontal Ribbon Mixer

Brand Name:	WeSeW
MOQ:	1 pc
Price:	US$15,000~US$30,000 per pc
Supply Ability:	10,000 pieces per month

Detail Information

Product Description

Detail Information

Place of Origin:

china

Certification:

CE/UL

Model NO.:

Kai003

Key Selling Points:

Easy To Operate

Machinery Test Report:

Provided

Application Scope:

Food Pharmacy Chemical

Core Components:

Motor, Gearbox

Color:

Clients Request

Transport Package:

Wooden Box

Specification:

Customized

Trademark:

WESEW

Origin:

China

Supply Ability:

500000/Year

Package Size:

150.00cm * 50.00cm * 50.00cm

Package Gross Weight:

80.000kg

After-sales Service:

Provided

Warranty:

1 Year

Material Processed:

Plastics, Chemicals, Food, Medicine

Customization:

Available Customized Request

Shipping Cost:

About Shipping Cost And Estimated Delivery Time.

Currency:

US$

Return&refunds:

You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Packaging Details:

Wooden Case

Supply Ability:

10,000 pieces per month

Highlight:

High Mixing Capacity Powder Mixer

Easy To Operate Powder Mixer

Industrial Machine Powder Mixer

Product Description

Easy to Operate Industrial Powder Mixer with High Mixing Capacity

Custom Stainless Steel Horizontal Ribbon Mixer

OEM custom auger conveyor stainless steel horizontal ribbon mixer with CE certification, designed for efficient powder blending across multiple industries.

Mixer Type	Ribbon
Material Processed	Plastics, Chemicals, Food, Medicine
Spindle Speed Range	38-40 r.p.m
Condition	New
Application	Powder Mixing
Voltage	220V, 380V or optional
Material Options	SUS304, SUS304L, SUS316, SUS316L, Stainless steel
Effective Volume	180-210L
Core Components	Motor, Gearbox
Warranty	1 Year

Key Features:

Easy to operate with high efficiency mixing
CE certified for quality assurance
Machinery test report provided
Video outgoing-inspection available
Custom color options available per client request

Product Overview

The horizontal ribbon mixer utilizes internal and external ribbons on the stirring shaft to create comprehensive material movement within the mixing barrel. The inner spiral belt pushes materials from the center to the sides, while the outer spiral belt moves materials from the sides back to the center, establishing a continuous convection circulation system.

This advanced agitation mechanism ensures materials are rapidly and uniformly mixed in minimal time, making it a highly efficient mixing solution with broad application versatility, strong adaptability, and exceptional performance results.

Industrial Applications

Our horizontal ribbon mixer serves diverse sectors including chemical processing, battery materials, paints, dyes, pesticides, pharmaceuticals, food production, feed manufacturing, additives, refractory materials, new materials development, electronic plastics, ceramics, fertilizers, metallurgy, mining operations, dry mortar production, and specialized building materials.

The system efficiently handles powder-to-solid and powder-to-liquid mixtures, with mixing efficiency that significantly outperforms conventional cone mixers.

Product Gallery
