Custom Magnetic Separation Machine Full Auto Wet Magnetic Drum Separator

Custom Magnetic Separation Machine Full Auto Wet Magnetic Drum Separator

Brand Name:	WeSeW
Model Number:	AC0017-3
MOQ:	1 pc
Price:	US$100,000~US$200,000 per pc
Payment Terms:	T/T,Western Union
Supply Ability:	10,000 pieces per month

Detail Information

Product Description

Detail Information

Place of Origin:

china

Certification:

CE/UL

Material Feature:

Heat Resistant

Energy Saving:

Energy Saving

Color:

Clients Request

Condition:

New

Applicable Industries:

Manufacturing Plant, Energy & Mining

Dimension(L*W*H):

Customized

Transport Package:

Wooden Box

Trademark:

WeSeW

Production Capacity:

500000/Year

Material:

Stainless Steel

Certification:

ISO9001:2000, CE

Warranty:

1 Year

Customized:

Customized

After-sales Service:

Provided

Machinery Test Report:

Provided

Core Components:

Coil

Specification:

Customized

Origin:

China

Packaging Details:

Wooden Case

Supply Ability:

10,000 pieces per month

Highlight:

Custom Magnetic Separation Machine

Full Auto Wet Magnetic Separator

Magnetic Drum Separator

Product Description

Custom Magnetic Separation Machine - Full Auto Wet Magnetic Drum Separator

OEM Custom High Intensity Magnetic Automatic Separation Wet Magnetic Separator designed for efficient iron removal from various materials.

Product Specifications

Applicable Industries	Manufacturing Plant, Energy & Mining
Type	Magnetic Separator
Voltage	Customer Local Standard
Marketing Type	Ordinary Product
Video Inspection	Provided
Core Components	Coil
Condition	New
Warranty	1 Year
Test Report	Provided
Color	Multi Color
Transport Package	Wooden Case
Customization	Customized
Application	Iron Removal From Silica Sand/Feldspar

Working Principle

The system places a matrix net inside the working chamber surrounded by screw coils. AC power is converted to DC excitation power through a silicon rectifier control system. When the coil is energized, the matrix becomes magnetized, creating a non-uniform magnetic field on its surface - a high gradient magnetic field. As slurry passes through the matrix inside the working chamber, magnetic materials are absorbed by the matrix while non-magnetic materials pass through, effectively separating magnetic from non-magnetic substances.

Wet Chamber Type Features

High magnetic field with uniform distribution, high gradient, and effective iron removal
Oil bubble coil cooling system with forced water cooling ensures oil temperature rise within 10°C, extending electromagnetic wire service life
Import material brake valve with durable construction and no residual slurry overflow after closing
Special magnetic vibration mode perfectly removes impurities for 20-600 mesh materials
Lower power consumption compared to same-size alternatives
Increased capacity through special flow method design
Wide material compatibility (sand, mud, powder, etc.)
Fully automatic operation with easy and fast de-ironing

Application Scope

Fully automatic slurry electromagnetic separator is widely used to remove iron powder, micro-iron powder, and magnetic substances in slurry and glaze across ceramics, mining, chemical, electronics, and food industries. Particularly effective for removing iron and other magnetic impurities from raw clay mud in the ceramic industry.

Product Display
