U-shaped Horizontal Spiral Belt High-efficiency Heat Resistant Powder Mixer for Industrial Applications

U-shaped Horizontal Spiral Belt High-efficiency Heat Resistant Powder Mixer for Industrial Applications

Brand Name:	WeSeW
Model Number:	GB-717
MOQ:	1 pc
Price:	Price Negotiation
Payment Terms:	T/T,Western Union
Supply Ability:	10,000 pieces per month

Detail Information

Product Description

Detail Information

Place of Origin:

china

Certification:

CE/UL

Customization:

Available Customized Request

Power Source:

Electric

Discharge Method:

Manual

Core Components:

Motor

Safety Features:

Emergency Stop Button

Speed Control:

Variable Speed

Additional Capabilities:

Drying

Material Feature:

Heat Resistant, Fire Resistant

Packaging Details:

Wooden Case

Supply Ability:

10,000 pieces per month

Highlight:

U Shaped Powder Mixer

High Efficiency Powder Mixer

Horizontal Spiral Belt Powder Mixer

Product Description

U-shaped Horizontal Spiral Belt High-efficiency Powder Mixer

This industrial powder mixer features a U-shaped cylindrical structure with positive and negative rotating spiral belts that deliver exceptional mixing performance across various industries.

Key Features

Efficient Mixing with Low Energy Consumption: U-shaped design and spiral belt configuration ensure low-resistance material movement with intense convective and shear mixing effects
High Uniformity with Low Breakage Rate: Multi-layer spiral blades create vortices that accelerate mixing speed while minimizing crystal damage
Wide Material Compatibility: Suitable for powder-to-powder mixing and viscous materials, with capability to incorporate large amounts of liquid during processing

Industry Applications

Pharmaceutical Industry: Mixing raw materials to ensure uniform drug composition and quality
Food Industry: Blending powdered ingredients including flour, sugar, milk powder, seasonings, and additives
Chemical Industry: Processing various chemical raw materials such as zinc oxide, detergents, additives, and calcium carbonate
Construction Industry: Mixing mortar, gypsum, and other building materials for improved uniformity and strength
Paint and Dye Industry: Blending pigments and additives to ensure consistent color and product quality

Technical Specifications

Attribute Category	Description/Specification
Product Name	U-shaped Horizontal Spiral Belt High-efficiency Powder Mixer
Structural Form	U-shaped cylindrical body with continuous spiral belts inside
Drive Method	Driven by motor reducer, located on the end face of the equipment
Mixing Characteristics	Stable mixing with minimal crystal destruction; overall motion state requiring high power; short mixing time
Material Adaptability	Mixing of powders with powders and viscous materials; capable of incorporating large amounts of liquid
Material State	Solid powders, viscous substances
Spiral Belt Design	Inner and outer layers are left-hand and right-hand spirals respectively; the inner layer is wider than the outer layer, creating intense convective and shear mixing effects
Number of Blade Layers	Typically made in two or three layers
Mixing Effect	Generates vortices, accelerating mixing speed and improving mixing uniformity
Energy Efficiency	Low power consumption, high efficiency
Loading Coefficient	High
Application Fields	Pharmaceutical, food, pesticide, chemical, construction, paint, dye, feed, and many other industries
