Customized Screw and Barrel for Injection Molding Machine Barrel widely used across industries such as automotive, medical, and packaging

Name: Customized Screw and Barrel for Injection Molding Machine Barrel widely used across industries such as automotive, medical, and packaging
Brand: Guangzhou Kaixi Wisdom Valley Technology Co.,Ltd
SKU: W009
Price: 100.00 USD
Availability: InStock

Brand Name:	WeSeW
Model Number:	W009
MOQ:	1 pc
Price:	US$200~US$1,000 per pc
Payment Terms:	T/T,Western Union
Supply Ability:	1000000pcs per month

Detail Information

Product Description

Detail Information

Place of Origin:

china

Certification:

CE/UL

Model NO.:

W009

Plastic Processed:

PE, Po, PP, PVC, TPU, PBT, Pet, PLA, Etc.

Product Type:

Profile Extrusion Molding Machine

Feeding Mode:

Multiple Feed

Assembly Structure:

Integral Type Extruder

Screw:

Single-Screw

Engagement System:

Full Intermeshing

Screw Channel Structure:

Deep Screw

Exhaust:

Exhaust

Automation:

Automatic

Computerized:

Computerized

Product Name:

Screw And Barrel For Injection Molding Machine Barrel

Service:

OEM/ ODM

Surface Treatment:

Customized

Dimension(L*W*H):

Customized

Key Selling Points:

High-Accuracy

Transport Package:

Bag, Carton, Wooden Case, Customize

Specification:

Customized

Trademark:

WESEW

Origin:

China

Supply Ability:

500000/Year

Package Size:

100.00cm * 20.00cm * 20.00cm

Package Gross Weight:

50.000kg

After-sales Service:

Provide

Warranty:

12 Months

Type:

Pipe Extruder

Customization:

Available Customized Request

Shipping Cost:

About Shipping Cost And Estimated Delivery Time.

Currency:

US$

Return&refunds:

You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Screw Design:

Plastify Extruder Single Screw Barrel

Packaging Details:

Wooden Case

Supply Ability:

1000000pcs per month

Highlight:

customized screw barrel set

injection molding machine screw barrel

industrial screw barrel for automotive

Product Description

Customized Screw and Barrel for Injection Molding Machine

Widely used across industries such as automotive, medical, and packaging

Product Specifications

Application	Film blower, Cast film machine
Screw barrel material	38CrMOALA, SACM645, Sprayed dual alloy, etc.
Screw diameter	Φ30-Φ150
Aspect ratio	L/D=15-35
Overall hardness	HRC58°-68°
Nitriding depth	0.4mm-0.7mm
Straightness	0.015mm-1000mm
Scope of application	PE, PO, PP, PVC, TPU, PBT, PET, PLA, etc.
Technical indicators	Conditioning time 72H, Tempering hardness HB260-290, Gas vacuum nitriding time 168H, Nitride hardness HRC62-65°
Processing method	Vacuum nitriding, high frequency quenching, alloy spraying, electroplating hard chromium layer
Condition	New
Warranty	1 Year
Package	Wooden box

Notice: We only accept product customization, please be sure to contact us before placing an order.

Product Overview

The screw is the main core component of the injection molding machine. The quality of the screw determines the quality of the final product. The plasticizing screw of the injection molding machine has the functions of conveying, melting, mixing, compressing, metering and exhausting, making it a key factor affecting the quality of plasticizing.

Screw Material Classification

HPT Fully Hardened Powder Alloy Screw: Made of tungsten-cobalt powder alloy tool steel with overall hardening. Hardness: HRC65°. Suitable for transparent products, precision products, and high-temperature corrosive plastics like LCP, PES, PPA with fiber.
Double Alloy Screw: Base material SACM645 and 38CrMoAlA with tungsten carbide nickel-based alloy spray. Hardness: HRC60°. Suitable for transparent products and engineering materials like PA6, PA66 with fiber.
Electroplating Screw: Base material SACM645 and 38CrMoAlA with hard chromium, nickel, or titanium plating. Hardness: HRC60°. Suitable for PC, PMMA, PET transparent materials and corrosive U-PVC plastics.
Stainless Steel Screw: Material 9Cr18MoV stainless tool steel with overall hardening. Hardness: HRC55°.
SKD61 Screw: Made of Hitachi SKD61 material with special processing for enhanced toughness and torsion resistance.
Ordinary Nitrided Screw: Base material SACM645 and 38CrMoAlA with nitride layer depth 0.5-0.8mm. Hardness: HV980~1080°. Suitable for ordinary plastics like PP, ABS, PS, AS, PVC.

Screw Segment Functions

Injection Molding Machine Screw Feeding Section

Fixed groove depth section responsible for preheating, conveying and pushing plastic solids. Ensures plastic begins melting at the end of the feed section.

Injection Molding Machine Screw Compression Section

Tapering groove depth section for melting, mixing, shearing compression and pressurized exhaust of plastic raw materials. Plastic completely dissolves here with volume shrinkage. Compression ratio design is critical.

Injection Molding Machine Screw Homogenization Section

Fixed groove depth section for mixing, melt transportation, and metering. Provides sufficient pressure to maintain uniform melt temperature and stabilize plastic flow rate.
