Sand screw Washer Spiral Sand Washing Machine high cleaning efficiency Energy Saving Mining Equipment wear-resistant steel Screw Sand Washer Machine for Gravel Pebble Basalt

Sand screw Washer Spiral Sand Washing Machine high cleaning efficiency Energy Saving Mining Equipment wear-resistant steel Screw Sand Washer Machine for Gravel Pebble Basalt

Brand Name:	WeSeW
Model Number:	Kai001
MOQ:	1pcs
Price:	US$20,000~US$80,000 per pc
Payment Terms:	T/T,Western Union
Supply Ability:	10000pcs per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,UL

Material:

Stainless Steel/custom

Material Feature:

Heat Resistant, Fire Resistant

Application:

Chemical Industry, Grain Transport, Mining Transport, Power Plant

Core Components:

Motor

Dimension(L*W*H):

Customized

Specification:

Customized

Structure:

Conveyor System

Packaging Details:

Wooden Case

Supply Ability:

10000pcs per month

Highlight:

energy saving sand screw washer

wear-resistant spiral sand washing machine

gravel pebble basalt sand washer

Product Description

Industrial Spiral Screw Sand Washing Machine

The Spiral Sand Washing Machine is engineered to clean and separate dirt, dust, and impurities from sand, gravel, and crushed stone. Utilizing a rotating screw mechanism with water injection, this equipment delivers superior cleaning performance for construction, mining, and aggregate industries, ensuring high-quality materials for concrete production and various applications.

Key Features & Benefits

Performance Advantages

High Cleaning Efficiency: Effectively removes dirt, clay, and organic impurities to improve product quality
Low Water Consumption: Environmentally friendly operation with reduced water usage compared to other methods
Simple Structure & Easy Maintenance: Fewer moving parts minimize wear and reduce maintenance costs
Durable Construction: Built with wear-resistant steel to withstand harsh working conditions

Technical Specifications

Product Name	Industrial Spiral Screw Classifier Sand Washing Machine
Motor Type	AC Motor
Capacity	6-400t/h
Core Components	Bearing, Gearbox, Motor
Weight	500 KG
Applications	Motorway construction, hydropower projects, building material washing, classification, and contaminant removal

Working Principle

The Spiral Sand Washer operates through a synergistic process of agitation, settling, and material transportation. As sand-cement slurry enters the inclined trough, rotating spiral blades agitate the mixture while gravity settles heavier sand particles. Lighter impurities remain suspended and are washed away by continuous water flow. The spiral conveyor lifts cleaned sand up the slope while discharging excess water through tank holes, delivering dewatered, purified material for downstream processing.

Environmental Protection Measures

Our spiral sand washers incorporate comprehensive environmental safeguards including water recycling systems with closed-loop circuits and sedimentation tanks to minimize freshwater consumption and wastewater discharge. Dust suppression via sprinklers and enclosed conveyors controls airborne particulates, while noise-dampening technology reduces operational noise. The system includes wastewater treatment with chemical flocculation and pH balancing to ensure compliance with environmental discharge standards.

Technical Parameters

Model	Spiral Diameter (mm)	Water Tank Length (mm)	Feed Size (mm)	Spiral Speed (r/min)	Processing Capacity (t/h)	Motor Power (kw)
LX915	915	7585	10	21	100	11
2LX915	915	7585	10	21	200	11*2
LX1115	1115	7620	10	17	175	15
2LX1115	1115	7620	10	17	350	15*2
LX1500	1500	7680	10	12	50-150	18.5
2LX1500	1500	7680	10	12	100-300	18.5*2
