Stainless Steel High Efficiency Tubular Screw Auger Conveyor for Customized Bulk Material Handling

Stainless Steel High Efficiency Tubular Screw Auger Conveyor for Customized Bulk Material Handling

Brand Name:	WeSeW
Model Number:	conveyor 1
MOQ:	1 pc
Price:	US$8,000~US$30,000 per pc
Payment Terms:	T/T,Western Union
Supply Ability:	10,000 pieces per month

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin:

china

Certification:

CE/UL

Material Feature:

Heat Resistant, Fire Resistant

Width Or Diameter:

Customized

Structure:

Conveyor System

Material:

Stainless Steel

Feature:

High Efficiency

Machinery Test Report:

Provided

Function:

Transmission System

Usage:

Conveyor

Customization:

Available Customized Request

Dimension(L*W*H):

Customized

Speed:

High Speed

Application:

Chemical Industry, Grain Transport, Mining Transport, Power Plant

Applicable Industries:

Manufacturing Plant, Food & Beverage Factory...

Packaging Details:

Wooden Case

Supply Ability:

10,000 pieces per month

Highlight:

Stainless Steel Screw Auger Conveyor

High Efficiency Tubular Screw Conveyor

Customized Spiral Conveyor

Product Description

Stainless Steel Tubular Screw Conveyor for Bulk Material Handling

Product Overview

Structure	Conveyor System
Material	Stainless Steel
Material Feature	Oil Resistant, Heat Resistant, Fire Resistant
Application	Chemical Industry, Grain Transport, Mining Transport, Power Plant
Condition	New
Voltage	220V/380V
Function	Conveying Equipment
Specification	SS304

Horizontal Carbon Steel Screw Feeder

Screw conveyor is widely used in various industries, including pharmaceutical, chemical, metallurgy, mining, construction, and food industries. Suitable for horizontal, inclined or vertical conveying of powder, granular, liquid and small block materials.

Working Principle: The rotating spiral blade transfers materials. Material weight and friction resistance against the conveyor shell prevent material from rotating with the screw conveyor blade.

Key Advantages

Material options include carbon steel, 304 stainless steel, or 316 stainless steel based on customer requirements

Adjustable conveying speed with uniform feeding without blockage

Well-known brand pure copper motors with reducers for simpler maintenance and durability

Professional electric control box for integrated operation with crushers, vibrating screens, and mixers

Customizable feeding hoppers according to customer requirements

Product Specifications

Shaft Screw Conveyor

Model	Diameter (mm)	Rotate Speed (rpm)	Conveying Capacity (m³)
DZLS 108	Φ108	186	2
DZLS 133	Φ133	140	3
DZLS 159	Φ159	140	5.5
DZLS 168	Φ168	140	6.5
DZLS 219	Φ219	93	11
DZLS 273	Φ273	88	20
DZLS 325	Φ325	88	33
DZLS 356	Φ356	88	44
DZLS 426	Φ426	65	50

Suitable Materials: Flour, cement, lime, grain, sand, pulverized coal, sawdust, salt, etc.

* We can customize according to customer requirements

DZWLS Shaftless Screw Conveyor

Model	Diameter (mm)	Rotate Speed (rpm)	Conveying Capacity (m³)
DZWLS 200	Φ200	65	4
DZWLS 260	Φ260	65	8
DZWLS 300	Φ300	52	10
DZWLS 360	Φ360	43	14
DZWLS 400	Φ400	43	19
DZWLS 440	Φ440	43	31

Suitable Materials: Bark, wheat straw, sugar containing water, kitchen waste, sludge, coke, sulfur ore, etc.

* We can customize according to customer requirements

Technical Features

Equipment Type: Tubular screw conveyor for continuous material transport
Main Material: Stainless steel tube conveying chamber
Core Structure: Enclosed tubular casing, internal screw flight, drive motor, inlet, and support legs
Operational Characteristics: Fully sealed conveying prevents material spillage and dust emissions

Core Functions & Applications

Primary Function: Uses rotating screw flight to propel materials axially for horizontal or inclined transport
Typical Materials: Powdery, granular, and small-lump materials including grains, cement powder, food-grade powders, and chemical granules
Key Advantages: Compact design, small footprint, flexible routing, easy maintenance, sealed dust-free transfer

Application Areas

Widely used in construction materials, grain processing, food and pharmaceuticals, chemicals, and environmental dust control. Standard conveying component in bulk material handling lines with customizable length and tube diameter.
