Large Capacity Sawdust Auger Conveyor Systems For Mining Transport

Name: Large Capacity Sawdust Auger Conveyor Systems For Mining Transport
Brand: Guangzhou Kaixi Wisdom Valley Technology Co.,Ltd
SKU: Kai001
Price: 15.00 USD
Availability: InStock

Brand Name:	WeSeW
Model Number:	Kai001
MOQ:	1 pc
Price:	US$10,000~US$20,000 per pc
Payment Terms:	T/T,Western Union
Supply Ability:	10,000 pieces per month

Detail Information

Product Description

Detail Information

Place of Origin:

china

Certification:

CE/UL

Model NO.:

Kai001

Material:

Stainless Steel

Material Feature:

Heat Resistant, Fire Resistant

Application:

Chemical Industry, Grain Transport, Mining Transport, Power Plant

Condition:

New

Applicable Industries:

Manufacturing Plant, Food & Beverage Factory...

Machinery Test Report:

Provided

Usage:

Conveyor

Width Or Diameter:

Customized

Dimension(L*W*H):

Customized

Function:

Transmission System

Feature:

High Efficiency

Speed:

High Speed

Transport Package:

Wooden Box

Specification:

Customized

Trademark:

WESEW

Origin:

China

Supply Ability:

500000/Year

Package Size:

800.00cm * 50.00cm * 50.00cm

Package Gross Weight:

200.000kg

After-sales Service:

Provided

Warranty:

1 Year

Structure:

Conveyor System

Customization:

Available Customized Request

Shipping Cost:

About Shipping Cost And Estimated Delivery Time.

Currency:

US$

Return&refunds:

You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Packaging Details:

Wooden Case

Supply Ability:

10,000 pieces per month

Highlight:

Sawdust Auger Conveyor Systems

Large Capacity Auger Conveyor Systems

Large Capacity Screw Conveyor Machine

Product Description

Large Capacity Sawdust Auger Conveyor Systems For Mining Transport

OEM Custom Cooling or Heating Optional U Trough Double Auger Screw Conveyor

Auger Types	Single/Twin/Multi screw
Instrumentation	Temperature in/out readout, Flowmeters, Variety of pressure gauges available, Customized control panels
Seal Types	Rotating Mechanical, Packing Gland, Custom
Heaters/Coolers	Single, dual or triple zone configurations, -50°F to 600°F temperature control, Designed for your needs
Jacket Types	Heating jackets, Cooling jackets, Integral or bolt-on, ASME "U" and "R" stamp
Customization	Inlet and outlet custom designs, Built-to-order support stands, NDE and X-ray options, Various insulation options
Sample Applications	Drying, Polymerization, Heat curing, Cooling/freezing, Microbial kill, Sintering/calcining, Dewatering

Product Overview

Heat Systems screw conveyors are simple, robust and flexible, often employed to adjust the temperature of solid materials prior to storage or further processing. The unit functions as a screw conveyor with integrated heat transfer capability, providing both material movement and temperature adjustment in one efficient device.

Unlike conventional systems that rely solely on external jackets with limited material contact due to voidage and movement, our screw conveyors utilize both the screw itself and external surfaces to transfer heat. This dual approach penetrates deep into materials that are typically poor conductors (such as spent carbon), resulting in a more compact footprint and reduced costs.

A liquid heat transfer medium ensures stable and precise control of final product temperature (using cooling water, thermal oil, glycol, etc.). Custom screw conveyor designs are available to meet your specific requirements.

Key Features

Thermal Processing

Thermal treatment during material conveyance for cost savings
Precise temperature control during material transfer
Accurate control of thermal treatment time
Greater heat transfer surface area per unit than batch mixer systems
Bolt-on or integral external thermal heating and cooling jacket

Performance Advantages

Efficient heat transfer with heated vessel and rotor
Short-pitch screw design promotes gentle material tumbling
Near plug-flow operation for consistent time and temperature exposure
Minimizes processing damage (burning, sticking, abrasion)
Twin-rotor designs for difficult, dough or paste-like materials
Optional steam injection for cooking or sterilizing
Lower operating costs with increased efficiency

Industry Applications

Heating and cooling screw conveyors are used globally across multiple industries including biomass conversion, paper and pulp, biofuels, food and dairy, chemicals, petrochemicals, minerals processing, and many other industrial applications.
