High-Precision Heat Resistant Corrosion Resistant Auger Screw for PP Pipes Extruder Screw

High-Precision Heat Resistant Corrosion Resistant Auger Screw for PP Pipes Extruder Screw

Brand Name:	WeSeW
Model Number:	kx auger717
MOQ:	1 pc
Price:	Price Negotiation
Payment Terms:	T/T,Western Union
Supply Ability:	10,000 pieces per month

Detail Information

Product Description

Detail Information

Place of Origin:

china

Certification:

CE/UL

Thread Coverage:

Fully Threaded

Shape:

Spiral

Material Feature:

Heat Resistant, Fire Resistant

Shaft Length:

Customize

Structure:

Conveyor System

Surface Treatment:

Customized

Corrosion Resistance:

Yes

Function:

Conveyor Bulk Material

Packaging Details:

Wooden Case

Supply Ability:

10,000 pieces per month

Highlight:

PP Pipes Auger Screw

High Precision Auger Screw

Uniform Plasticization Auger Screw

Product Description

High-Precision Auger Screw for PP Pipes

This high-precision auger screw features exceptional extrusion capabilities and excellent material compatibility, ensuring uniform plasticization for PP pipe manufacturing. Engineered with advanced wear-resistant materials and precise parameter calculations, it delivers superior performance in plastic processing applications.

Auger Screw Features

Designed for optimal performance in plastics processing, this auger screw combines high efficiency, exceptional wear resistance, precision engineering, and energy-saving operation. The extruder screw for blow molding machines incorporates optimized design elements that ensure efficient extrusion and precise control throughout the production process.

Enhanced Durability: Manufactured using high-wear-resistant materials suitable for long-term continuous production
Precision Engineering: Precisely calculated screw parameters combined with advanced control systems
Superior Wear Resistance: Special treatments enhance hardness and extend service life for HDPE pipe applications
Uniform Plasticization: Efficient extrusion and precise temperature control ensure consistent material quality
Material Compatibility: Compatible with PP, PE, and PPR materials without chemical reactions during extrusion
Energy Efficient: Environmentally conscious design reduces energy consumption and carbon emissions

Industry Applications

Automotive Industry: Production of fuel tanks, bumpers, and interior trim components from HDPE, PP, and PE materials

Building & Construction: Manufacturing pipes and fittings for plumbing, irrigation, and drainage systems

Packaging Industry: Production of plastic containers and bottles for food, beverages, and household chemicals

Agricultural Equipment: Durable plastic components including tanks, housings, and covers for machinery

Electronics & Electrical: Cable conduits, electrical boxes, and junction boxes requiring precision extrusion

Technical Specifications

Product	Material Base	Treatment/Processing	Technical Parameters	Application
Screw	38CrMoAlA	Nitriding	Temper hardness: HB260-280 Nitriding hardness: HV950 Nitride layer depth: 0.4-0.6mm Brittleness: ≤ 2.5 Surface finish Ra0.04	Ordinary acid-free plastics with low particle size and no GF (ABS, PP, PS)
Screw	38CrMoAlA	Bimetallic Nickel-Based Alloy	Alloy thickness: ≥ 1.5mm Hardness: HRC53-56 Brittleness: ≤ 2.5 Surface finish Ra0.04	Acidic plastics with GF addition less than 30%
Screw	42CrMo	Bimetallic Nickel-Based Alloy + Plating	Alloy thickness ≥ 1.5mm Plating thickness: 0.03-0.05mm Hardness: HRC52-55	Transparent materials/blended color materials
Screw	Fully Hardened Powder Metallurgy Steel	Vacuum Quenching Process	Quenching hardness: HRC57-59 Plating thickness: 0.03-0.05mm	Engineering plastics with 35% GF or less, high-temperature materials (PA+GF/LCP+GF/high-temperature PC)
Screw	Fully Hardened Powder Metallurgy Steel	Vacuum Quenching Process	Quenching hardness: HRC59-61 Thickness: 0.005-0.01mm	Engineering plastics with 45% GF or less
Barrel	38CrMoAlA	Nitriding	Temper hardness: HB260-280 Nitriding hardness: HV950 Nitride layer depth: 0.4-0.6mm Brittleness: ≤ 2	Acid-free plastics with GF addition less than 10% (PP, PS, AS, ABS, TPU, TPE)
Barrel	38CrMoAlA	Bimetallic Iron-Based Alloy	Alloy thickness: 1.5-2mm Surface hardness: HRC60-65	Acidic plastics with GF addition less than 30% (PC/PA)
Barrel	38CrMoAlA	Bimetallic Nickel-Based Alloy + 15% Tungsten Carbide Powder	Alloy thickness: 1.5-2mm Surface hardness: HRC52-55	Acidic plastics with GF addition less than 35% (PA/LCP/PBT)
Barrel	38CrMoAlA	Bimetallic Nickel-Based Alloy + 25% Tungsten Carbide Powder	Alloy thickness: 1.5-2mm Surface hardness: HRC58-62	Plastics with added elastic PEEK/PPS/LCP/flame retardants
