Custom High-Torque Double Diaphragm Coupling Rigid Coupling with Zero Maintenance and Corrosion Resistant for Drive Equipment

Custom High-Torque Double Diaphragm Coupling Rigid Coupling with Zero Maintenance and Corrosion Resistant for Drive Equipment

Brand Name:	WeSeW
Model Number:	CNC0184
MOQ:	1pcs
Price:	US$5~US$50 per pc
Payment Terms:	T/T,Western Union
Supply Ability:	10,000 pieces per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE, ISO9001/UL

Name:

Flexible Star Couplings

OEM/ODM:

OEM ODM CNC Milling Turning Machining Service

Material Capabilities:

Aluminum, Brass, Bronze, Copper, Hardened Metals

Application:

Metal Cutting Machine, Metal Straightening Machinery, Metal Spinning Machinery, Metal Processing Machinery Parts, Metal Forging Machinery, Metal Engraving Machinery, Metal Drawing Machinery, Metal Coating Machinery, Metal Casting Machinery

Standard:

DIN, ASTM, GOST, GB, JIS, ANSI, BS

CNC Machining Or Not:

CNC Machining

Micro Machining Or Not:

Micro Machining

Processing Method:

Customer′s Engineering Drawing

Packaging Details:

Wooden Case

Supply Ability:

10,000 pieces per month

Highlight:

High-Torque Double Diaphragm Coupling

Zero Maintenance Rigid Coupling

Corrosion Resistant Two-Shaft Axial Connection

Product Description

Custom High-Torque GLT Two-Stage Rigid Coupling

This two-step double-diaphragm coupling provides reliable two-shaft axial connection for torque transmission and drive equipment applications.

Product Specifications

Applicable Industries:

Production workshop, repair shop, other

Material:

Aluminium

Standard or Nonstandard:

Standard

Structure:

Universal

Customized Support:

Standard

Flexible or Rigid:

Rigid

Aperture:

5-38mm

Rated Torque:

2-90 Nm

Key Features

Designed for servo and stepper motors
Zero gap between shaft and sleeve connection, suitable for forward and reverse rotation
Low inertia design, optimized for high-speed operation
Diaphragm made of spring steel with excellent fatigue resistance

The double-step double-diaphragm coupling is a high-performance flexible transmission component that connects two sets of diaphragms via an intermediate shaft, specifically engineered to address complex shaft misalignment challenges.

Working Principle

Utilizes elastic three-dimensional deformation generated by dual diaphragm assemblies at both ends of the intermediate shaft to transmit torque from the driving shaft to the driven shaft. Compared to single-diaphragm structures, it can flex simultaneously in multiple directions, more efficiently absorbing combined axial, radial, and angular misalignment while eliminating additional stresses.

Core Advantages

Zero Maintenance: Requires no lubrication or seals
Zero Backlash: No rotational clearance during operation
High Efficiency: Transmission efficiency up to 99.86%
Enhanced Compensation: Dual-step design provides twice the angular displacement capacity of single-diaphragm types
Corrosion Resistant: Resists acid and alkali corrosion
Temperature Range: Withstands extreme environments from -80°C to 300°C
Long Service Life: Exceeds 10 years of reliable operation

Applications

Widely used in heavy-duty equipment such as high-power fans, chemical pumps, and compressors, as well as precision scenarios demanding exceptional transmission accuracy and stability—including aerospace and semiconductor manufacturing applications.

Product Images
